Vinci SubVision Solid™ | Annotated 4d Underground Construction Site Detail

The 4d worksite section is a great instrument for explaining underground construction. This section works much like an “ant farm” toy; the section is taken along the centerline of the planned tunnel. This simple section shows how the tunnel boring machine is aimed to miss a layer of unstable rock. The interpolated stratigraphic information presented here derives from public geological data available on the Internet. The first part of this animation is the chapter head page of a Vinci CentNav™ presentation. In the presentation environment, this page contains links to other segments of the presentation and the Home Page →.
